Specifications

• Dimensions

  add remove
  • Length:
    93.1 in
  • Seat height, unladen:
    28.3 in
  • Rake (steering head):
    28
  • Trail:
    5.7 in
  • Wheelbase:
    63.6 in
  • Tires, front specifications:
    110/90B19,62H,BW
  • Tires, rear specifications:
    180/70B16,77H,BW
  • Fuel Capacity:
    5.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    694 lbs
  • Weight, in running order:
    721 lb
  • Luggage capacity – volume:
    1.9 cu ft (0.05 m³)
  • Tire, type:
    Michelin® Scorcher® "31" front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    117.35 in³
  • Compression ratio:
    10.2:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 offset shotgun; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    124.6 ft-lb
  • Engine torque (RPM):
    3500
  • Horsepower:
    103 HP / 77 kW @ 4750 rpm
  • Lean angle, right (deg.):
    31.3
  • Lean angle, left (deg.):
    31.3
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    47 mpg (5 l/100km)
  • CO₂ emissions testing method:
    –
  • CO₂ emissions :
    –
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Single cartridge 43 mm inverted with aluminum fork triple clamps; single rate spring
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
  • Wheels, front type:
    Dark bronze, Radiate cast aluminum wheel
  • Wheels, rear type:
    Dark bronze, Radiate cast aluminum wheel
  • Brakes, type:
    Front and rear black, Split 7-spoke floating rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    All LED, low beam, high beam and signature position lamp, LED Zeppelin tail lamp, Incandescent bullet turn signals
  • Gauges:
    2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication
