The 2025 Harley-Davidson® Breakout® Centerline with Laced Wheels is a striking representation of power and style, seamlessly blending modern engineering with classic aesthetics. This motorcycle features a robust and muscular design, characterized by its low-slung stance and elongated profile that exudes confidence and performance.


At its heart, the Breakout® is powered by a high-performance Milwaukee-Eight® 114 engine, delivering impressive torque and acceleration for an exhilarating riding experience. The bike's Centerline design emphasizes sleek, aerodynamic lines, enhancing both its visual appeal and its capability on the open road.


One of the standout features of this model is its laced wheels, which not only add a touch of vintage charm but also provide enhanced durability and stability. These wheels are complemented by premium finishes and meticulous attention to detail, ensuring that every ride is not just a journey, but an adventure.


The 2025 Breakout® also boasts modern technology, including advanced suspension systems for a smoother ride, state-of-the-art braking systems for superior safety, and a digital interface for easy access to essential information. Whether you're cruising through city streets or exploring open highways, this motorcycle offers an unrivaled blend of heritage and innovation, making it a true icon in the Harley-Davidson® lineup.

Specifications

  • Dimensions
    add remove
    • Length:
      93.5 in
    • Seat height, unladen:
      26.2 in
    • Ground clearance:
      4.5 in
    • Rake (steering head):
      34
    • Trail:
      5.7 in
    • Wheelbase:
      66.7 in
    • Tires, front specifications:
      130/60B21,63H,BW
    • Tires, rear specifications:
      240/40R18,79V,BW
    • Fuel Capacity:
      5.0 gal
    • Oil capacity:
      5 qt.
    • Weight, as shipped:
      655 lbs
    • Weight, in running order:
      681 lb
    • Tire, type:
      Michelin® Scorcher 11, front and rear
  • Engine
    add remove
    • Engine:
      Milwaukee-Eight® 117 Custom
    • Bore:
      4.1 in
    • Stroke:
      4.5 in
    • Displacement:
      117.35 in3
    • Compression ratio:
      10.3:1
    • Fuel system:
      Electronic Sequential Port Fuel Injection (ESPFI)
    • Exhaust:
      2-into-2 staggered; catalyst in muffler
  • Performance
    add remove
    • Engine torque testing method:
      EC 134/2014
    • Engine torque:
      126.1 ft-lb
    • Engine torque (RPM):
      3000
    • Horsepower:
      104 HP / 77 kW @ 4800 rpm
    • Lean angle, right (deg.):
      26.8
    • Lean angle, left (deg.):
      26.8
    • Fuel economy testing method:
      EU 134/2014
    • Fuel economy:
      49 mpg (4.8 l/100 km)
  • Powertrain
    add remove
    • Primary drive:
      Chain, 34/46 ratio
    • Gear ratios (overall) 1st:
      9.311
    • Gear ratios (overall) 2nd:
      6.454
    • Gear ratios (overall) 3rd:
      4.793
    • Gear ratios (overall) 4th:
      3.882
    • Gear ratios (overall) 5th:
      3.307
    • Gear Ratios (overall) 6th:
      2.79
  • Chassis
    add remove
    • Front fork:
      Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring
    • Rear shocks:
      Hidden, free piston, coil-over monoshock; 43mm stroke; hydraulic preload adjustment
    • Wheels, front type:
      Gloss black, 26-spoke cast aluminum
    • Wheels, rear type:
      Gloss black, 26-spoke cast aluminum
    • Brakes, type:
      Front and rear black, Split 7-spoke floating rotors
    • Brakes, caliper type:
      4-piston fixed front and 2-piston floating rear
